Introduction to CSS Grid: Mastering 2D Layouts

Before CSS Grid, creating complex website layouts often required hacky floats or rigid tables. CSS Grid is a powerful layout engine built directly into the browser that allows you to align elements into rows and columns without needing external frameworks like Bootstrap.

Lesson Overview

What you will learn: How to initialize a grid and define basic columns and rows.
Key concepts: Grid Container, Grid Items, and the fr (fractional) unit.
Expected outcome: You will be able to build a basic responsive hero layout.

To start using Grid, you must define a container. Any direct children of that container automatically become grid items.

Step 1: The HTML Structure

First, we need a parent element (the container) and several nested elements (the items). Copy this into your HTML file:

<div class=”grid-container”>
<div class=”grid-item”>1</div>
<div class=”grid-item”>2</div>
<div class=”grid-item”>3</div>
<div class=”grid-item”>4</div>
</div>

Step 2: Define the Container in CSS

Apply display: grid to the parent class. This “activates” grid properties for all children.

.grid-container {
display: grid;
/* A fixed 200px sidebar and a flexible main area that fills the rest */
grid-template-columns: 200px 1fr;
gap: 20px; /* Creates consistent spacing between items */
}
.grid-item {
background-color: #3498db;
color: white;
padding: 20px;
text-align: center;
}

Step 3: Understanding the fr Unit

The fr unit represents a fraction of the available space. Unlike percentages, fr units automatically handle the math for your gap settings so nothing overflows the screen.

Step 4: Creating Rows

While columns are the most common focus, you can also set specific row heights to maintain structure:

.grid-container {
display: grid;
grid-template-columns: repeat(3, 1fr); /* Creates three equal columns */
grid-template-rows: 100px auto; /* First row is 100px, second fits content */
}

Playground

See the Pen CodePen Demo

Assignment

Task 1
Copy the HTML structure from Step 1. Use CSS Grid to arrange the four items into a 2×2 square where every box is exactly 200px by 200px.

Task 2
Update your CSS so that the four items appear in a single row. The first item should take up 50% of the total width, and the remaining three items should split the rest of the space equally using the fr unit.
